Garrett ACE 150/250 Instruction Manual
This official Garrett ACE 150/250 instruction manual serves as an essential guide for users—whether you're brand-new or replacing a misplaced manual. It delivers accurate, manufacturer-approved instructions.
What’s Covered in the Manual:
Assembly Instructions
Step-by-step assembly guidance: connect search coil, lower and upper stems, wrap cable properly, and secure the control housing.
Controls & Display Guide
Detailed overview of the control panel and LCD, including:
- Target ID cursor and upper/lower scales
- Eight sensitivity levels and depth indicators (2", 4", 6", 8"+)
- Battery condition icon
- Discrimination notch elimination (DISCRIM/ELIM buttons)
These advanced features distinguish ACE 250 from the ACE 150
Operating Modes
Descriptions of key detecting modes:
- All-Metal
- Jewelry
- Coins
- Relics (ACE 250 only)
- Custom — user-programmable discrimination notches retained after power-off.
Pinpoint Mode
In-handle pinpointing: hold button and sweep coil for accurate “X-ing” over targets, with depth shown via LCD segments.
Sensitivity & Discrimination
Adjustable to eight sensitivity levels for varying conditions. ELIM button allows exclusion (‘notching’) of nuisance targets. CUSTOM mode settings stored after shutdown.
Target ID System
12-segment upper scale with numerical ID 0–99, plus 3-tone audio signals (low, mid, high conductors) for target identification.
Troubleshooting & Maintenance
Covers battery installation, coil care, factory-reload procedure (press-and-hold POWER for ~5–10 s), and a troubleshooting guide. Includes warranty and service details.
